Aruba Instant On 1830 8G 4p Class4 PoE 65W Switch JL811A
General Specifications
- Model: Aruba Instant On 1830 8G 4p Class4 PoE 65W Switch (JL811A)
- Ports: 8 x 10/100/1000BASE-T ports (4 x PoE-enabled)
- PoE Budget: 65W (Class 4 PoE)
- Switching Capacity: 20 Gbps
- Forwarding Rate: 14.88 Mpps
- Layer Support: Layer 2 switching
Aruba Instant On 1830 8G 4p Class4 PoE 65W Switch JL811A
General Specifications
- Model: Aruba Instant On 1830 8G 4p Class4 PoE 65W Switch (JL811A)
- Ports: 8 x 10/100/1000BASE-T ports (4 x PoE-enabled)
- PoE Budget: 65W (Class 4 PoE)
- Switching Capacity: 20 Gbps
- Forwarding Rate: 14.88 Mpps
- Layer Support: Layer 2 switching
Product Details
The Aruba Instant On 1830 8G 4p Class4 PoE 65W Switch JL811A is a smart-managed, compact, and cost-effective Layer 2 switch, designed for small businesses, home offices, startups, and retail environments. With 8 Gigabit Ethernet ports, including 4 Class 4 PoE ports, it delivers power and connectivity to devices such as IP phones, access points, and security cameras. The 65W PoE budget ensures efficient power allocation while maintaining energy efficiency. With cloud-based management via the Aruba Instant On mobile app and web portal, this switch provides easy setup, robust security, and reliable performance.
Specifications Table
| Category | Specification |
|---|---|
| Model | Aruba Instant On 1830 8G 4p Class4 PoE 65W Switch (JL811A) |
| Port Configuration | 8 x 10/100/1000BASE-T ports (4 x PoE-enabled) |
| PoE Budget | 65W (Class 4 PoE) |
| Switching Capacity | 20 Gbps |
| Forwarding Rate | 14.88 Mpps |
| Layer Support | Layer 2 |
| Management | Aruba Instant On Cloud, Web GUI, SNMP |
| Power Consumption | Max 80W, Idle 6.8W |
| Security Features | VLANs, ACLs, 802.1X authentication, MAC filtering |
| Mounting Options | Desktop, rack-mountable |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Certifications | FCC, CE, RoHS |
